Chapter 5. Peripheral Equipment
Section
3004nstallation
External General Page/UNA Installation
Use this procedure to connect a general page system, connect UNA over a
page system or connect a combined page/UNA system.
1.
Connect
CN4
on the DBS Connector Panel to the audio input of the
paging amplifier. (See Figure 5-8.)
2.
Connect the audio output of the amplifier through the C and M relay
terminals to the speaker(s) as shown in Figure 5-8.
Figure
5-8.
External general
pagelUNA
insMution
(RCA
ki%kstor)
S%4
SS%
RG
+24V
GND C
B
M
ZO
Zl
22
Z3
24
RE2
RI3
1
Notes:
l
Instead of the described combined Paging/UNA configuration, most often
Universal Night Answer notification is
provided by an external ringer
device. (See “External Ringer (UNA Device)” on page 5-17 for more
information on UNA external ringer
de\
ice installation.)
5-16
DBS
Manual
-
Issued WV95
DBS-70-300
