Cliapter 7. Specifications Section 300~Installation
Communication Parameters
Tuble 7-12. Voice path from KTELs to DBS
n
Channel
Overall conununicadons path
1 D-channel data
1256 kbps
116 kbps
1 B-channel data
164 kbps
Table 7-13. Data communications ports
Parameters
ISMDR
Interface
RS233-C
Baud rate
300,1200,4800 or 9600 kbps
Parity Even, odd, or none
Stop bit length
1, 1.5, or 2
Data bit length 5, 6,7, or 8
1 Maintenance (RAI card) Baud rate
300 (RAI-A) or 300 or 1200 (RAI-B)
Stop bit length
1
Data bit length 8
. Parity
None
