Section 3004nstallation
Chapter 7. Specifications
Signaling Characteristics
Table 7-14. Signaling to CO
Item
Specification
Dial pulse 8 to 11 pulses per second (PPS)
Break ratio 58 to 64%
Minimum pause
0.7 to 1.0 seconds
Trunk start
Loop or ground start
Table 7-15. Signaling le vets
Item
Level
Distortion
Trunk input (DISA)
-40
dBm (minimum) Less than 10%
Output
from DBS (at MDP) High level: -8 dBm (minimum)
Low level: -10
dBm (minimum)
Analog station input (Dial -35
dBm (minimum)
Less than 10%
status)
Analog station output (Talk High level: -8 dBm+/-0.5 dBm
Less than 5%
Path originated from a keY Low level: -6 dBm+/-0.5 dBm
phone to an SLT)
Table 7-16. Transmission specifxations
Item
bnpedance
Overload level
bertion Loss
CO trunk to analog station
Analog station to CO trunk
CO trunk to digital station
Digital station to CO trunk
Digital station to digital station
Digital station to analog station
Analog station to digital station
Analog station to analog station
Specification
600 Ohms
600 Ohms
OdB
OdB
OdB
OdB
6dB
6 dB
6dB
6dB
DBS-70-300
DBS Manual
- Issued 8/T/95
7-15
