Chapter 6. Double-Cabinet Systems
Section
300~installation
Insta lla tio n
1.
Install the trunk and extension cards according to the layouts shown in the
Figures
5-l
through 6-6.
Note: The port numbers for each slot are fixed.
2.
If you are using two MFR cards, cut Strap S3 on the second card.
Figure 6-7. Strap 3, MFR card
I
3.
Using the cables provided, connect the CBL-M card in the master cabinet
to the CBL-S card installed in the slave cabinet.
Note: The EM1 filter must be installed as close to the cabinet as possible,
as shown in Figure 6-8 on page 6-l 1.
6-10
DBS Manual
-
Issued
8/l/95
DBS-70400
