Section
300~Installation
Chapter 5. Peripheral Equipment
Local Terminal or SMDR Device
Guidelines
l
Connector 6 (CN6) on
the
Connector Panel provides an RS-232C interface
for connection of a local programming terminal or an SMDR device such
as a printer or
call accounting machine.
l
The following table contains RS-232C designations.
Table 5-l. RS-232C pin designations used
for
CN6
Pin
Signal Name Description
1
N/A
2
TD
3
RD
4
CTS
Not used.
Transmit Data
Receive Data
Clear to Send
5
RTS
6
DSR
7
SG
8
CD
Request to Send
Data Set Ready
Signal Ground
Carrier Detect
20
1
Data Terminal Ready
l
For instructions on connecting a remote PCAS PC, see the
PCAS User’s
Guide.
l
For instructions on connecting
the
remote DBS Manager, see the
DBS
Manager User
Guide.
DBS-70-300 DBS Manual
-
Issued
U/95
5-3
