Panasonic DBS 40 - Tmnk Connector Pinouts

The number of trunks that can be connected through the main trunk connector
depends on the type of system you have and the number of trunk cards
installed. Table 4-l shows the main trunks and expansion trunks available
with each system type. Chapter 6 includes trunk maximums for two-cabinet
systems.
Table 4-l. Main trunks and expansion trunks provided with each sy stem type
Sys tern Type
Main Trunk Numbers Expansion Trunk Numbers
DBS 40 1-8 9-16
DBS 72 1-16 17-24
DBS 96
l-24
25-32
Trunk Connector Pinouts
Table 4-2 includes pinouts and color codes for the main trunk connector.
Table 4-3 shows
pinouts and color codes for the trunk expansion connector.
* Instructions on installing the expansion connector begin on 4-43.
4-4 DBS Manual - issued 8/l/95
