Table 4-19. Extension ports provided with each system
System Type
DBS 40
DBS 72 1-48
DBS 96 l-72
Extension Ports
(Not including the Expansion Connector*)
l-24
*Note: Extensions 65 to 72 on the DBS 96 use the EC/TRK slot, but they
do not require the extension expansion connector. If extensions 65 to 72 are
used, the trunk expansion connector cannot be used.
Extension Connector Pinouts
Tables 4-20 through 4-22 provide pinouts and color codes for extension
slots.Table 4-22 on page 4-35 provides pinouts and color codes for the
extension expansion connector.
Instructions on installing the expansion connector begin on 4-43.
