Section
300~Installation
Chapter 4. Trunks and Lines
Lines
Extension Connectors
The number of extension ports that can be connected to your system depends
on the type of system you have.
Egure
4-13 shows the maximum number of
extensions that can be connected to each system when the extension
expansion connector is used.
Table 4-l summarizes the number of ports that can be used without the
extension expansion connector. Chapter.6 includes extension maximums for
two-cabinet systems.
mre 4-13. DBS extension connections
To
CNI
on
ths
Extension
49-56
To
To
To
Expansion Connector
m-43121
Extension 25
Extension 32
Extension 1
Extension 24
Extension 25
DES
72
J
and 96
Extension 46
Extension 49
‘I
J
DSS
96
only
Extension 72
DBS-70-300
DBS Manual
-
Issued
8/1’/95
4-31
