Panasonic DBS 40 - Guidelines; Installation

Section 300~Installation Chapter 3. Cabinet Installation
G ro unding
Guidelines
l Before grounding the DBS, read the “Lightning Protection/Grounding”
requirements beginning on page l-6.
l The ground cable must be at least 18 AWG.
l Resistance to ground must be 10 Ohms or less.
Installation
1. Attach the ground cable to the ground screw on the front of the power
suPPlY*
.
2.
Connect the ground cable to the building ground.
Figure 3-4.
Ground Screw
DBS-70-300
DBS Manual - Issued 8/l/95
3-5
