Chapter 3. Cabinet Installation
Battery-
Guidelines
l
The DBS 40 uses two
12-volt
batteries; the DBS 72 and 96 use four 6-volt
batteries or two 12-volt batteries. The following table includes the part
numbers for the battery packages.
Table 3-I.
Battery backup packages
for
the DBS 40, 72, and 96
System
Battery Backup Part No.
DBS 40
VB-43130 (some systems may be
equipped with
VB-2450A-2P)
DBS 72 and 96
VB-43 130 (some systems may be
equipped with VB-2650-2P)
l
The backup batteries are connected in a series circuit, using cables
provided with the DBS.
l
With maximum traffic, the backup batteries last up to 40 minutes for the
DBS 40 and 72, and up to 30 minutes for the DBS 96.
l
The backup batteries should be replaced about every 3 years.
RECYCLE
THE PRODUCT YOU HAVE PURCHASED MAY CONTAIN SEALED LEAD
ACID BATTERIES WHICH ARE RECYCLABLE. AT THE END OF THEIR
USEFUL LIFE, UNDER VARIOUS STATE AND LOCAL LAWS, IT IS ILLEGAL
TO DISPOSE OF THESE BATTERIES INTO YOUR MUNICIPLE WASTE
STREAM. PLEASE CALL
l-800-SAV-LEAD FOR INFORMATION ON HOW TO
RECYCLE THESE BATTERIES.
DBS-70-300
DBS Manual
-
Revised
S/22/97
3-9
