Chapter 3. Cabinet Installation
Section
3004nstallation
Test Phone
Guidelines
l
The test terminal (CN3) on the DBS Connector Panel can be used to
connect a display phone for programming.
The test terminal can be used for initial programming before extension
cabling is completed.
l
The test terminal is turned on by flipping SW1 on the Connector Panel to
the “Test” position. When SW 1 is in the test position, extension ports 7 and
8 are connected through the test terminal. When SW1 is not in the test
position, extension ports 7 and 8 are connected through the
MDE
Note: Before using the test terminal on a DBS that is operational, be sure
the phones connected to ports 7 and 8 can be taken out of service.
l
A
DSS/72
can be connected to the display phone for text entry. Port 7 must
be assigned as extension 101 and the DSS/72 must be assigned as
telephone type 13 for the
DSS/72 to operate.
Installation
-
1.
Connect the telephone and DSS (optional) to CN3 on the Connector
Panel. (See Figure,3-18 on page
3-
19.)
2.
Set SW 1 to “Test.”
3.
When programming is completed, set SW 1 back to “ST.”
3-1
a
DES
Manual
-
Issued
8/l/95
DBS-70-300
