Chapter 5. Peripheral Equipment
Section
300~Installation
Requirements
l
Trunks used for Door Boxes and openers must be set up as dial pulse
trunks.
l
Equipment combinations used with the Door Box Adaptor require the
number of trunks in the following table:
Ifyouuse...
The adaptor uses
I
1 sensor and 1 Door Box/opener
1
2 trunks
1 sensor and 2 Door Boxes/open-
2
trunks
ers
1 sensor
1 Door Box/opener
ltrunk
ltrunk
l
The following tools are required to install the Door Box Adaptor:
-
Phillips screwdriver
-
Needle-nose pliers
-
Diagonal shears.
Installation
1.
Remove the cover from the Door Box Adaptor.
2.
Set the switches in the Door Box Adaptor as shown in Figure 5-16.
3.
Remove the cable punch-out plate Figure 5-12 in order to make an
opening for the cables coming into the Door Box Adaptor.
To remove the plate, cut the grooves on either side with diagonal shears.
Then bend the plate back and forth with needle-nose pliers to remove it.
5-28
DBS Manual
-
Issued
8/l/95
DBS-70400
