DOCIIU~
mu-insrarlarm
Table S-IO. Switch settings
for
abbreviated dialing
digit
length, VAU
Switch Block 2 (SW2)
Abbreviated Dialing Digit Length (Switches 7-8)
Switch
Number of Digits
1 Digit
2
Digits
3 Digits
7
OFF
OFF
ON
8
OFF
ON
OFF
3.
Remove the cable punch-out plate (Figure 5-12) to make an opening for
the cable coming into the VAU.
To remove the plate, cut the grooves on either side with diagonal shears.
Then bend the plate back and forth with needle-nose pliers to remove it.
Figure 5-12. Cable punch- out plate, Voice Announce Unit
P
able
Punch-Ot
late
4.
Mount the VAU on the wall using the three screws provided with the unit.
(See Figure
5-
14.)
5.
Connect the extension cable from the DBS to
CNl
on the VAU.
Note:
The two inside pins on
CNl
are port 1. The two pins on either side
are port 2, as shown in Figure 5-13.
5-24
DBS Manual
-
Issued
8/l/95
DBS-70-300
