Section
300~Installation
Chapter 5. Peripheral Equipment
Table S- 11. Maximum
distrurces
for SLTA installation
Wiring
Max. distance (in feet) between
Max. distance (in feet) between
fF”!.F
the DBS and SLTA
the SLTA and the SLT
AWG 22
300’
or
10
n
3000’ or
100
SI
AWG 24
190’
or
10
Sz
1900’
or
100
rZ
AWG 26
120’ or 10
Q
1200’ or 100
n
4.
5.
6.
7.
8.
9.
If
the DBS is powered up, turn off the power.
Connect the GND and
+24V leads on the SLTA to the DBS connector
panel.
Be sure the wires do not touch each other or touch the metal
frame housing.
Turn on the DBS power.
Connect the “T” and “R” leads to the digital extension ports on
the DBS
as per Figure 5-21. One digital extension port is required for each
SLT.
Connect the SLT “T” and “R” leads to the
SLTs.
Install the cover on the SLTA.
DBS-70-300 DBS Manual
-
Issued
8/l/95
5-35
