Chapter 6. Double-Cabinet Systems
Section
3004nstallation
F iaure
6-3. Slot usdwe
for two-cabinet
svstems.
DBS 72 + DBS 72
DBS 72 (Slave)
TRK TRK EC1 EC2 EC3 EC4 EC5 EC6 EC/
SCC CPC AUX AUX
1 2 TRK 1 2
s
74 %
4
2
G
g
DBS 72 (Master)
TRK TRK EC1 EC2 EC3 EC4 EC5 EC6 EC/
SCC CPC AUX AUX
1 2 TRK
1 2
%
Notes:
*See “Tl Interface” on page 4-11 for EC/TRK port numbers for Tl.
Beginning with CPC-B Version 4, the EC/TRK slot in the slave DBS 72 can be used for
trunks or lines. Prior to CPC-B Version 4, this slot could only be used for lines.
#A maximum of two MFR cards can be installed in a two-cabinet system. With Cable Kit
Version 1.1, one MFR is installed in the Master AUXl, and one MFR is installed in the Slave
AUXl . With Cable Kit Version 1.2, both MFR cards are installed in the slave cabinet--one
in the CPC slot and one in AUXl. (When two MFR cards are used, Strap S3 on the second
card must be cut.)
6-6
DES Manual - Issued 8/l/95 DES-70-300
