Inde x
A
Analog extensions 4-37
guidelines 4-37
installation 4-37
see also SLTA
B’
Background music
see Peripheral equipment, BGM
Battery backup
capacities 7-3
guidelines 3-9
installation 3-9
DBS 40 3-10
DBS 72 and 96 3- 11
part numbers 3-9
specifications 7-3
BGM
see Peripheral equipment, BGM
C
Cabinet description 2-3
Cabinet installation 3- 1
batteries 3-9
guidelines 3-9
installation
DBS 40 3-10
DBS 72 and 96 3-l 1
circuit cards 3-6
guidelines 3-6
installation 3-8
DSLT wall mounting 3-15
desk stand attachment 3-16
desk stand removal
3- 15
grounding 3-5
guidelines 3-5
installation 3-5
initialization 3- 17
key phone wall mounting 3-13
mount adaptor removal 3-13
guidelines 3- 18
installation
3- 18
wall mounting 3-3
cover removal 3-3
guidelines 3-3
installation 3-3
mounting brackets 3-4
mounting illustration 3-4
Cabling
distances 7- 13
specifications
7- 13
Cards
see Circuit cards
Channel service unit 4-12
Circuit cards
CPC
description 2-9
strap S 1 3-7
SW1 3-17
installation 3-6,3-g
guidelines 3-6
MDF card 4-23
MFR slcts 2-8
SCC-B switch 4 3-6
slot locations 2-8
Cleaning 1-6
Clock sync cable 4-29
Communications parameters
7- 14
Configuration 2-5
extension capacities 2-5
trunk capacities 2-5
Connector panel 2-3
Connectors
pinouts for trunks 4-4
trunks 4-3
Cover removal 3-3
CPC
description 2-9
RAM clear 3- 17
RAM hold
3- 17
strap S 13-7
mount adaptor replacement
3- 14
SW1 3-17
test phone 3- 18
CSU 4-12
DES-70-300
DES Manual-Issued 8/l/95'
