Chapter 3. Cabinet Installation Section
300~Installation
Figure 3-12.
W all-mount adaptor replacement
igure
3-13.
Handset
Guide
3.
Turn the wall-mount adaptor around and re-attach it to the phone.
.
L
I.
Remove the handset guide with a small screwdriver, turn it over, and
reinsert it into the phone.
t guide insertion for wal
7-m-r
n
3
znting,
key phor
I
1
3-l 4
DES Manual
-
Issued
8/l/95
DBS-70-300
