Chapter 3. Cabinet Installation
Section
300~Installation
2.
Attach the desk stand to the bottom of the phone by aligning the tabs and
tab guides and sliding it into place (Figure 3-15).
Figure 3-15. Desk stand attachment for DSLT wail mounting
I
.
3.
Remove the handset guide with a small screwdriver, turn it over, and
reinsert it into the phone,
Figure
3-16.
Handset guide
insertian
for
waU-n
i
Handset
Guide
unting, DSLT
3-16
DBS Manual
-
Issued
6/l/95
DBS-70-300
