6.4 Component Names
This section presents the name and display content of each component of GM Programmer
.
No. Name Description
(1) Title bar
The title bar displays the project file name, [minimize] button, [maximize] button, and
[close] button.
(2) Menu bar The menu bar displays the menu commands for each purpose in list format.
(3) Toolbar The toolbar displays each command as an icon.
(4) Navigator pane
The navigator pane displays the objects (such as devices, applications, and programs)
added to the project in a tree structure.
(5) Main pane
The main pane displays a program, function settings, messages, and other data.
The window can be switched by selecting a desired tab.
(6) Status field The status bar displays the build status, logged-in users, and other information.
6.4 Component Names
6-10 WUME-GM1ETCSU-01
