Panasonic Lumix DMC-GH4 User Manual

4. Focus and Shutter (Drive Mode) Settings
98
Aim the AF tracking frame over the subject, and press the
shutter button halfway.
A AF tracking frame
• AF area will turn green when the camera detects the subject.
• The AF area turns yellow when the shutter button is released.
• Lock is canceled when [MENU/SET] is pressed.
Touch the subject.
• Perform the operation after canceling the touch shutter function.
• The AF area turns yellow while the subject is locked.
• Lock is canceled when [ ] is touched.
• If it fails to lock, AF area will flash in red, and disappear. Try to lock again.
• When AF tracking fails, [Ø] is set.
Locking the subject to be tracked ( [Tracking])
Button operation
Touch operation
A

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
