Panasonic Lumix DMC-GH4 User Manual

99
4. Focus and Shutter (Drive Mode) Settings
Selecting from 49 AF areas, you can freely set the optimum shape of the AF area for the
subject.
1 Press [].
2 Select a Custom Multi icon ([ ], etc.), and press 3.
•
If you press 4, the AF area setting screen will be displayed.
• You can also display the AF area setting screen by touching the screen.
3 Press 2/1 to select a setting.
•
The current shape of the AF area A is displayed on the
bottom left of the screen.
4 Press 4.
•
AF area setting screen is displayed.
5 Select AF areas.
•
The selected AF areas are displayed in yellow, while the areas that are not selected are
displayed in white.
Setting the shape of the AF area ([Custom Multi])
([Horizontal
Pattern])
Horizontal line
This shape is
convenient for taking
panning shots or
similar shots.
([Vertical
Pattern])
Vertical line
This shape is
convenient for
recording objects,
such as buildings.
([User
Defined])
Free shape
//
([Custom1]/
[Custom2]/
[Custom3])
You can select a customized setting.
FREE ヤビ ヤピヤヒ
A
FREE
ヤヒ
ヤビ
ヤピ

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
