Panasonic Lumix DMC-GX7 User Manual

157
Focus and Exposure Settings
Turning on/not turning on the AF Assist Lamp
AF assist lamp will illuminate the subject when the shutter button is pressed halfway,
making it easier for the camera to focus when recording in low light conditions. (Larger AF
area is displayed depending on the recording conditions.)
• The effective range of the AF Assist Lamp is different depending on the lens used.
– When the interchangeable lens (H-H020A) is attached: Approx. 1.0 m (3.3 feet) to 5.0 m
(16 feet)
– When the interchangeable lens (H-FS1442A) is attached and at Wide: Approx. 1.0 m
(3.3 feet) to 3.0 m (9.8 feet)
• The AF Assist Lamp is valid only for the subject in the centre of the screen. Use it by
positioning the subject in the centre of the screen.
• Remove the lens hood.
• When you do not want to use the AF Assist Lamp (e.g. when taking pictures of animals in dark
places), set the [AF Assist Lamp] to [OFF]. In this case, it will become more difficult to focus on
the subject.
• The AF Assist Lamp may be greatly blocked, and it may become harder to focus when a lens
with large diameter is used.
• The setting for the [AF Assist Lamp] is fixed to [OFF] in the following cases.
– [Distinct Scenery]/[Bright Blue Sky]/[Romantic Sunset Glow]/[Vivid Sunset Glow]/[Glistening
Water]/[Clear Nightscape]/[Cool Night Sky]/[Warm Glowing Nightscape]/[Artistic Nightscape]
(Scene Guide Mode)
Recording/not recording even when focus is not achieved
[FOCUS]:
You cannot take a picture until the subject is brought into focus.
[RELEASE]:
This gives priority to the best time to take a picture so you can take a picture when the
shutter button is pressed fully.
•
Keep in mind that when [RELEASE] is set, focus may not be achieved even if the focus mode
lever is set to [AF].
• [Focus/Release Priority] is disabled during motion picture recording.
Adjusting/not adjusting the focus manually after achieving Auto Focus
When AF Lock is ON (press the shutter button halfway with the [AFS/AFF/AFC] set to
[AFS] or set AF Lock using [AF/AE LOCK]), you can make fine adjustments to the focus
manually.
[MENU] > [Custom]>[AF Assist Lamp]>[ON]/[OFF]
[MENU] > [Custom]>[Focus/Release Priority]
[MENU] > [Custom]>[AF+MF]>[ON]/[OFF]

Panasonic Lumix DMC-GX7 Specifications

General

Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom	4 x
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Auto focusing (AF) modes	Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/320 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVCHD
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@50fps, 1920x1080@60fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Mini
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Portrait
Image editing	Crop, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	320 shots
Product color	Black, Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.2 PE

Weight and Dimensions

Depth	54.6 mm
Width	122.6 mm
Height	70.7 mm
Weight	360 g
Weight (including battery)	402 g
