Connecting to other equipment
Enjoying 3D pictures
Attaching the 3D interchangeable lens (H-FT012: optional) to the camera allows you to
take 3D pictures for extra impact.
To view 3D pictures, a television that supports 3D is required.
1
Attach the 3D interchangeable lens to the camera.
2
Bring the subject into the frame and record by pressing the shutter
button fully.
• Focusing is not required when recording 3D pictures.
• Still pictures recorded with the 3D interchangeable lens attached are saved in MPO
format (3D).
• Up to approx.490 3D pictures can be recorded on a 2 GB card. (When the aspect ratio is set to
[4:3], and the quality is set to [ ].)
• Read the operating instructions of the 3D interchangeable lens for details.
Not available in these cases:
•
You cannot record 3D pictures in vertical orientation.
• When a distance to the subject is 0.6 m (2.0 feet) to approximately 1 m (3.3 feet), horizontal
disparity becomes too great, and you may not see the 3D effect at the edges of the image.
Taking 3D pictures
To ensure that the 3D pictures can be safely viewed, pay attention to the
following points when recording.
•
Where possible, record with the unit in a horizontal state.
• The suggested minimum subject distance is 0.6 m (2.0 feet).
• Be careful not to shake the camera while in a vehicle or walking.
• It is recommended to use a tripod or a flash to record steady pictures.

Panasonic Lumix DMC-GX7 Specifications

General

Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom	4 x
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Auto focusing (AF) modes	Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/320 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVCHD
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@50fps, 1920x1080@60fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Mini
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Portrait
Image editing	Crop, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	320 shots
Product color	Black, Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.2 PE

Weight and Dimensions

Depth	54.6 mm
Width	122.6 mm
Height	70.7 mm
Weight	360 g
Weight (including battery)	402 g
