Recording Modes
Applicable modes:
The effects of aperture and shutter speed can be checked by using the Preview Mode.
•
Confirm the effects of aperture: You can check the depth of field (effective focus range)
before taking a picture by closing the leaf shutter to the aperture value you set.
• Confirm the effects of shutter speed: Movement can be confirmed by displaying the actual
picture that will be taken with that shutter speed. When the shutter speed is set for high speed,
display in the shutter speed preview will be displayed like a time-release film. It is used in cases
such as stopping the movement of running water.
1 Set a function button to [Preview]. (P47)
•
The following step is an example in which [Preview] is assigned to [Fn5].
2 Touch [ ].
3 Switch the confirmation screen by touching [Fn5].
•
The screen switches each time [Fn5] is touched.
Depth of field properties
¢1 Recording conditions
¢2 Example: When you want to take a picture with a blurred background etc.
¢3 Example: When you want to take a picture with everything in focus including the background
etc.
• It is possible to record while in Preview Mode.
• Range for shutter speed effect check is 8 seconds to 1/1000th of a second.
Confirm the Effects of Aperture and Shutter Speed (Preview Mode)
Normal recording screen Effects of Aperture Effects of Shutter Speed
¢1
Aperture value Small Large
Focus length of the lens Tele Wide
Distance to the subject Near Distant
Depth of field (effective focus range) Shallow (Narrow)
¢2
Deep (Wide)
¢3
Fn6Fn6Fn6
Fn5
Fn7
Fn8
Fn9
6KWU6SHHG(IIHFW2Q
Fn5
Fn6Fn6Fn6
Fn5
Fn7
Fn8
Fn9
6KWU6SHHG(IIHFW2II
Fn5
Fn6Fn6Fn6
Fn5
Fn7
Fn8
Fn9

Panasonic Lumix DMC-GX7 Specifications

General

Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom	4 x
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Auto focusing (AF) modes	Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/320 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVCHD
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@50fps, 1920x1080@60fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Mini
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Portrait
Image editing	Crop, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	320 shots
Product color	Black, Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.2 PE

Weight and Dimensions

Depth	54.6 mm
Width	122.6 mm
Height	70.7 mm
Weight	360 g
Weight (including battery)	402 g
