Page #349 background imageLoading...
Page #349 background image
349
Others
Operation of the unit, such as displaying of the screen and button operations, can be set
up according to your preferences. Also, it is possible to register the modified settings.
[Custom]
[Cust.Set Mem.] Registers the current camera settings as custom set. P128
[Silent Mode]
Disables operational sounds and output of light at
once.
P195
[AF/AE Lock]
Sets the fixed content for focusing and exposure when
the AF/AE lock is on.
P164
[AF/AE Lock Hold]
This will set the operation of [AF/AE LOCK] button
when taking a picture with fixed focus or exposure.
P165
[Shutter AF]
Set whether or not the focus is adjusted automatically
when the shutter button is pressed halfway.
P156
[Half Press Release]
The shutter will immediately fire when the shutter
button is pressed halfway.
P156
[AFS/AFF/AFC]
Sets the focus method.
P147
[Quick AF]
Speeds up the focusing that takes place when you
press the shutter button.
P156
[Eye Sensor AF]
The camera automatically adjusts the focus when the
eye sensor is active.
P64
[Pinpoint AF Time]
Sets the time for which the screen is enlarged when the
shutter button is pressed halfway with Auto Focus
Mode set to [ ].
P155
[AF Assist Lamp]
AF assist lamp will illuminate the subject when the
shutter button is pressed half-way making it easier for
the camera to focus when recording in low light
conditions.
P157
[Direct Focus Area]
Moves the AF area or MF assist using the cursor
button when recording.
P155,
P161
[Focus/Release Priority]
It will set so no picture can be taken when it is out of
focus.
P157
[AF+MF]
You can set the focus manually after the automatic
focus has finished.
P157
[MF Assist]
Sets the display method of MF Assist (enlarged
screen).
P159

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX7 and is the answer not in the manual?

Panasonic Lumix DMC-GX7 Specifications

General IconGeneral
Camera typeMILC Body
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom4 x
Optical zoom- x
Focal length range- mm
Lens mount interfaceMicro Four Thirds (MFT)
Minimum aperture number-
Auto focusing (AF) modesContrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeMechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/320 s
Power source typeBattery
Video resolutions1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVCHD
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1920x1080@50fps, 1920x1080@60fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1040000 pixels
USB version2.0
USB connectorMini-USB B
HDMI connector typeMini
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesBacklight, Portrait
Image editingCrop, Rotating
Photo effectsVivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
Diopter adjustment (D-D)-4 - 3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)320 shots
Product colorBlack, Silver
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2 PE
Weight and Dimensions IconWeight and Dimensions
Depth54.6 mm
Width122.6 mm
Height70.7 mm
Weight360 g
Weight (including battery)402 g
