Panasonic Lumix DMC-GX7 User Manual

303
Wi-Fi/NFC
Search for available wireless access points.
• Confirm encryption key of the selected wireless access point if the network authentication is
encrypted.
• When connecting by [Manual Input], confirm SSID, encryption type, encryption key of the
wireless access point you are using.
1 Select the wireless access point you are connecting
to.
•
Pressing [DISP.] will search for a wireless access point
again.
• If no wireless access point is found, refer to “When
connecting with [Manual Input]
” on P303.
2 (If network authentication is encrypted)
Enter the encryption key.
•
For details on how to enter characters, refer to “Entering Text” section on P61.
∫ When connecting with [Manual Input]
1 On the screen displayed in step 1 of “If you are not sure about the WPS
compatibility (connecting by [Manual Connection])”, select [Manual Input].
2 Enter the SSID of the wireless access point you are connecting to, then select
[Set].
•
For details on how to enter characters, refer to “Entering Text” section on P61.
3 Select the network authentication type.
•
For information on network authentication, see the manual of the wireless access point.
4 Select the encryption type.
•
The type of settings that can be changed may vary depending on the details of network
authentication settings.
5 (When an option other than [No Encryption] is selected)
Enter the encryption key.
•
Check the wireless access points instruction manual and settings when saving a wireless
access point.
• If no connection can be established, the wireless access point’s radio waves may be too weak.
Refer to
“Message Display” (P341) and “Troubleshooting” (P355) for details.
• Transmission speed may decrease, or may not be usable depending on the environment it is
used in.
If you are not sure about the WPS compatibility (connecting by [Manual
Connection])
Network authentication type Encryption types that can be set
[WPA2-PSK]/[WPA-PSK] [TKIP]/[AES]
[Common Key] [WEP]
[Open] [No Encryption]/[WEP]

Panasonic Lumix DMC-GX7 Specifications

General

Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom	4 x
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Auto focusing (AF) modes	Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/320 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVCHD
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@50fps, 1920x1080@60fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Mini
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Portrait
Image editing	Crop, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	320 shots
Product color	Black, Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.2 PE

Weight and Dimensions

Depth	54.6 mm
Width	122.6 mm
Height	70.7 mm
Weight	360 g
Weight (including battery)	402 g
