Panasonic Lumix DMC-GX7 User Manual

313
Connecting to other equipment
Connecting the camera to a 3D compatible television and playing back pictures taken in
3D allows you to enjoy 3D pictures for extra impact.
It is also possible to play back the recorded 3D pictures by inserting an SD card into the
3D compatible television with an SD card slot.
Connect the unit to a 3D compatible television using the HDMI mini cable
and display the playback screen. (P315)
• When [VIERA Link] (P58) is set to [ON] and the camera is connected to a TV supporting VIERA
Link, input of the TV will be switched automatically and playback screen will be displayed.
Refer to P318 for details.
• For the pictures recorded in 3D, [ ] will appear on the thumbnail display at playback.
∫ Playback in 3D by selecting only the still pictures recorded in 3D
Select [3D Play] in [Playback Mode] in the [Playback] menu. (P245)
∫ Playback as a 3D slide show by selecting only the still pictures recorded in 3D
Select [3D] in [Slide Show] in the [Playback] menu. (P242)
∫ Switch the playback method for the still pictures recorded in 3D
1 Select the picture recorded in 3D.
2 Select [2D/3D Settings] on the [Playback] menu. (P40)
•
Playback method will switch to 3D if it is playing back in 2D (conventional image), or it will
switch to 2D if it is playing back in 3D.
• If you feel tired, uncomfortable or otherwise strange when playing back pictures recorded
in 3D, set to 2D.
∫ Functions that cannot be set/do not work with 3D pictures
•
[Highlight]
¢
([Custom] menu)
• Playback Zoom
¢
• Editing functions of [Playback] menu ([Location Logging]
¢
/[Clear Retouch]/[Title Edit]/[Text
Stamp]/[Video Divide]/[Time Lapse Video]
¢
/[Stop Motion Video]
¢
/[Resize]/[Cropping]/[Rotate]/
[Favorite]
¢
/[Print Set]
¢
/[Protect]
¢
/[Face Rec Edit])
¢ Can be used when displayed in 2D.
Playing back 3D pictures
Preparations: Set the [HDMI Mode] to [AUTO], [1080p] or [1080i]. (P57)
Set the [3D Playback] to [ ]. (P58)

Panasonic Lumix DMC-GX7 Specifications

General

Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom	4 x
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Auto focusing (AF) modes	Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/320 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVCHD
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@50fps, 1920x1080@60fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Mini
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Portrait
Image editing	Crop, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	320 shots
Product color	Black, Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.2 PE

Weight and Dimensions

Depth	54.6 mm
Width	122.6 mm
Height	70.7 mm
Weight	360 g
Weight (including battery)	402 g
