362
Others
In dark places, noise may appear to maintain the brightness of the monitor.
This is a characteristic of the drive system of the viewfinder of this unit, and it is not a
malfunction. There will be no problem with the recorded image.
You can display the pictures without being rotated when [Rotate Disp.] (P259) is set to [OFF].
You can rotate pictures with the [Rotate] function. (P259)
Did you press [(]?
Is the card inserted?
Is there a picture on the card?
Is this a folder or picture which was processed in the PC? If it is, it cannot be played back by
this unit.
> It is recommended to use the “PHOTOfunSTUDIO” software in the CD-ROM (supplied) to
write pictures from PC to card.
Has [Playback Mode] been set for playback?
> Change to [Normal Play]. (P245)
Is this a non-standard picture, a picture which has been edited using a PC or a picture which
was taken by another make of digital camera?
Did you remove the battery immediately after picture-taking or did you take the picture using a
battery with a low remaining charge?
> Format the data to delete the pictures mentioned above. (P60)
(Other pictures will be deleted as well and it will not be possible to restore them. Therefore,
check well before formatting.)
Noise appears on the monitor.
You see red, green, or blue flashes when you move your eyes in the viewfinder,
or when the camera is moved rapidly.
Playback
The picture being played back is not rotated, or is rotated in an unexpected
direction, when displayed.
The picture is not played back.
There are no recorded pictures.
The folder number and the file number are displayed as [—] and the screen turns
black.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX7 and is the answer not in the manual?

Panasonic Lumix DMC-GX7 Specifications

General IconGeneral
Camera typeMILC Body
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom4 x
Optical zoom- x
Focal length range- mm
Lens mount interfaceMicro Four Thirds (MFT)
Minimum aperture number-
Auto focusing (AF) modesContrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeMechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/320 s
Power source typeBattery
Video resolutions1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVCHD
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1920x1080@50fps, 1920x1080@60fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1040000 pixels
USB version2.0
USB connectorMini-USB B
HDMI connector typeMini
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesBacklight, Portrait
Image editingCrop, Rotating
Photo effectsVivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
Diopter adjustment (D-D)-4 - 3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)320 shots
Product colorBlack, Silver
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2 PE
Weight and Dimensions IconWeight and Dimensions
Depth54.6 mm
Width122.6 mm
Height70.7 mm
Weight360 g
Weight (including battery)402 g
