364
Others
Use within the communication range of the wireless LAN network.
Connection types and security setting methods are different depending on the wireless access
point.
> Refer to the operating instructions of the wireless access point.
When the radio waves are interrupted, the condition may improve by moving the location or
changing the angle of the wireless access point.
It may not automatically connect when the network SSID of the wireless access point is set not
to broadcast.
> Set the network SSID of the wireless access point to broadcast.
Is any device, such as microwave oven, cordless phone, etc., that uses 2.4 GHz frequency
operated nearby?
> Radio waves may get interrupted when used simultaneously. Use them sufficiently away
from the device.
Is the 5 GHz/2.4 GHz switchable wireless access point connected to other equipment using
the 5 GHz band?
> The use of a wireless access point that can use 5 GHz/2.4 GHz simultaneously is
recommended. It cannot be used simultaneously with this camera if it is not compatible.
When the battery indicator is flashing red, the connection with other equipment may not start or
the connection may be disrupted. (A message such as [Communication error] is displayed.)
Check if the wireless access point to connect is in operating state.
The camera may not display or connect to a wireless access point depending on the radio
wave condition.
> Perform the connection closer to the wireless access point.
It may not display even if the radio waves exist depending on the setting of the wireless access
point.
> Check the settings of the wireless access point.
The wireless access point may not be found depending on the radio wave condition.
> Perform the [Manual Connection]. (P303)
Is the network SSID of the wireless access point set not to broadcast?
> It may not be detected when it is set not to broadcast. Enter and set the network SSID.
(P303)
Try the following:
Move this unit closer to the wireless access point.
Remove the obstacles between this unit and the wireless access point.
Change the direction of this unit.
Wi-Fi function
It cannot connect to the wireless LAN. Radio waves get disconnected.
Wireless access point is not displayed. Or it cannot be connected.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX7 and is the answer not in the manual?

Panasonic Lumix DMC-GX7 Specifications

General IconGeneral
Camera typeMILC Body
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom4 x
Optical zoom- x
Focal length range- mm
Lens mount interfaceMicro Four Thirds (MFT)
Minimum aperture number-
Auto focusing (AF) modesContrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeMechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/320 s
Power source typeBattery
Video resolutions1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVCHD
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1920x1080@50fps, 1920x1080@60fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1040000 pixels
USB version2.0
USB connectorMini-USB B
HDMI connector typeMini
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesBacklight, Portrait
Image editingCrop, Rotating
Photo effectsVivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
Diopter adjustment (D-D)-4 - 3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)320 shots
Product colorBlack, Silver
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2 PE
Weight and Dimensions IconWeight and Dimensions
Depth54.6 mm
Width122.6 mm
Height70.7 mm
Weight360 g
Weight (including battery)402 g
