378
Others
Store the battery in a cool and dry place with a relatively stable temperature: (Recommended
temperature: 15 oC to 25 oC (59 oF to 77 oF), Recommended humidity: 40%RH to 60%RH)
Always remove the battery and the card from the camera.
If the battery is left inserted in the camera, it will discharge even if the camera is turned off. If
the battery continues to be left in the camera, it will discharge excessively and may become
unusable even if charged.
When storing the battery for a long period of time, we recommend charging it once a year.
Remove the battery from the camera and store it again after it has completely discharged.
We recommend storing the camera with a desiccant (silica gel) when you keep it in a closet or
a cabinet.
Check all the parts before taking pictures when you have not used the camera for a long
period of time.
Recorded data may be damaged or lost if the camera breaks down due to inappropriate
handling. Panasonic will not be liable for any damage caused due to loss of recorded data.
Images recorded or edited with the camera may not be played back correctly on other devices
and applied effects may not appear on the devices. Also, images recorded on other devices
may not be played back on the camera and functions of the camera may not be available for
the images.
When you use a tripod, make sure the tripod is stable when this unit is attached to it.
You may not be able to remove the card or the battery when using a tripod or unipod.
Make sure that the screw on the tripod or unipod is not at an angle when attaching or detaching
the camera. You may damage the screw on the camera if you use excessive force when
turning it. Also, the camera body and the rating label may be damaged or scratched if the
camera is attached too tightly to the tripod or unipod.
When using this unit with a large-diameter lens, the lens may come into contact with the
pedestal depending on the tripod/unipod. Tightening the screw with the lens and pedestal in
contact with each other may damage this unit or the lens. Therefore it is recommended to
attach the tripod adaptor (DMW-TA1: optional) before mounting on the tripod/unipod.
Read the operating instructions for the tripod or unipod carefully.
If you attach a heavy interchangeable lens (more than about 1 kg/35.3 oz) to the camera body,
do not carry the camera by the shoulder strap. Hold the camera and the lens when carrying
them.
When not using the camera for a long period of time
About the picture data
About tripods or unipods
About the shoulder strap

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX7 and is the answer not in the manual?

Panasonic Lumix DMC-GX7 Specifications

General IconGeneral
Camera typeMILC Body
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3232x1824, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
Digital zoom4 x
Optical zoom- x
Focal length range- mm
Lens mount interfaceMicro Four Thirds (MFT)
Minimum aperture number-
Auto focusing (AF) modesContrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeMechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/320 s
Power source typeBattery
Video resolutions1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVCHD
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1920x1080@50fps, 1920x1080@60fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1040000 pixels
USB version2.0
USB connectorMini-USB B
HDMI connector typeMini
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesBacklight, Portrait
Image editingCrop, Rotating
Photo effectsVivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
Diopter adjustment (D-D)-4 - 3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)320 shots
Product colorBlack, Silver
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2 PE
Weight and Dimensions IconWeight and Dimensions
Depth54.6 mm
Width122.6 mm
Height70.7 mm
Weight360 g
Weight (including battery)402 g
