5. Focus/Zoom
119
Setting Items ([Touch Pad AF])
[Focus Switching for Vert / Hor]
Memorizes separate positions for AF areas
for when the camera is vertically aligned and
for when it is horizontally aligned.
Two vertical orientations, left and right, are
available.
¨ [ ] ¨ [ ] ¨ Select [Focus Switching for Vert / Hor]
[EXACT]
Moves the AF area of
the viewfinder by
touching a desired
position on the touch
pad.
[OFFSET1]
to
[OFFSET7]
Moves the AF area of
the viewfinder
according to the
distance you drag
your finger on the
touch pad.
Select the range to be detected with the drag operation.
[OFFSET1] (entire area)/[OFFSET2] (right half)/[OFFSET3] (upper
right)/[OFFSET4] (lower right)/[OFFSET5] (left half)/[OFFSET6]
(upper left)/[OFFSET7] (lower left)
[OFF]
[ON] Memorizes separate positions for vertical and horizontal orientations.
[OFF] Sets the same position for vertical and horizontal orientations.
0
In MF, this memorizes the MF Assist position.
0
This does not work in the [ ] and [ ] to [ ] AF modes.
