Panasonic Lumix S5 User Manual

10. Recording Videos
268

When [BASE/RANGE] Was Selected with [SET]
Centerd on the brightness set with [Base Level], parts with the brightness
in the range set in [Range] are displayed with the stripes.
≥ [Base Level] can be set in the range between 0 % and 109 % (IRE).
≥ [Range] can be set in the range between n1 % and n10 % (IRE).
0
When [Photo Style] is set to [V-Log], these are set at “Stop” units.
(Calculated as “0 Stop”=42 % (IRE))
[Frame Marker]
A frame with the set aspect ratio is displayed on the recording screen.
This allows you to see during recording the angle of view that will be
achieved with trimming (cropping) in post-processing.
¨ [ ] ¨ [ ] ¨ Select [Frame Marker]
0 [ZEBRA1+2] cannot be selected while you are setting [BASE/RANGE].
[ON]
Displays the Frame Marker on the recording
screen.
[OFF] —
[SET]
[Frame Aspect]
Sets the aspect ratio of the Frame Marker.
[2.39:1]/[2.35:1]/[2.00:1]/[1.85:1]/[16:9]/[4:3]/
[5:4]/[1:1]/[4:5]/[9:16]
[Frame Color] Sets the color of the Frame Marker.
[Frame Mask]
Sets the opacity of the outside of the Frame
Marker.
[100%]/[75%]/[50%]/[25%]/[OFF]

Panasonic Lumix S5 Specifications

General

Style	Digital Single Lens Mirrorless
Color	Black
Image Sensor	35mm full-frame (35.6mm x 23.8mm) CMOS sensor
Crop Factor	1.0
Total Pixels	25.28 megapixels
Approx. 8.29 megapixels (3840 x 2160)	Approx. 30.4 megapixels
Image Processor	-
Lens Mount	L-Mount
Image Stabilization	Image sensor shift type (5-axis / 5.0-stop)
Dual I.S. (6.5-stop Dual I.S. 2 compatible)	-
Focusing	AFS (Single) / AFC (Continuous) / MF
Viewfinder Type	OLED Live View Finder
Shooting Modes	Landscape
Picture Styles: Auto	Fine Detail
Continuous Shooting	-
With Servo AF: Approx. 4 shots/sec	Up to 14fps with AF tracking UHS-II card support
Exposure Compensation	1/3 EV step ±5EV (±3EV for motion picture)
Automatic Exposure Bracketing (AEB)	-
ISO Sensitivity	1-Stop Display: [100]
ISO can be expanded to L:50	Auto (100-25600)
Shutter Speed	30-1/8000 sec (1/2 or 1/3 stop increments)
White Balance	Shade
Type	Touch screen Vari angle Clear View II TFT
Size	Free-angle
MP4 H.264	recording level can be manually adjusted by user)
MP4: H.264/MPEG-4 AVC	recording level can be manually adjusted by user)
ALL-I (FHD 29.97/25.00	HD - MPEG4 AVC / H.264 variable (average) bit rate
MP4 Video: Full HD (16:9) 1920 x 1080 - MPEG4 AVC/H.264	MOV (Video: H.264 Intra frame / inter frame
Max Movie Size	1920 x 1080 (59.94
1920 x 1080 (59.94	23.976 fps) IPB (Standard
1920 x 1080 ( 29.97	24
Full HD (16:9) 1920 x 1080 (59.94	23.98 fps) intra or inter frame
HD - 1280 x 720 (119.9	1920 x 1080 (29.97
640 x 480 (29.97	1280 x 720 (HD)
MP4: 4096 x 2160: 150Mbps 428 Mins	29 min 59 sec
Max Image Size	(1:1) 4640x 4640
RAW: (RAW) 6240 x 4160	(M1) 4464x2976
4:3 ratio (L) 5952x4480	(S3) 720x480
16:9 ratio (L) 6720x3776	(S3) 720x408
1:1 ratio (L) 4480x4480	(S3) 480x480
(RAW) 6720x4480	(4:3) 5328 x 4000
JPEG 1:1: (L) 4000 x 4000	JPEG: (L) 5472x3648
RAW: (RAW) 5472x3648	(M) 3984 x 2656
JPEG 4:3: (L) 5328x4000
JPEG 16:9: (L) 6000x3368
JPEG 1:1: (L) 4000x4000
Wireless Connectivity	GPS
Interface Connectors	XLR 3-pin connector x2
Storage Type	SD/SDHC memory card
1x SD/SDHC/SDXC and UHS-I	SD
Compact Power Adapter CA-CP200L: 24V DC	16Wh)
Battery life	AE 50%
Approx. 860 (at 0°C	Approx. 1200 shots (at 23°C
Approx. 980 (at 0°C	AE 50%
Operating Environment	(85% relative humidity);
Approx. -5 to 45°C	0 C to 40 C
Body Materials	-
Water / Dust resistance	-

Weight and Dimensions

Depth	78.5 mm
Height	105.2 mm
Width	139 mm
Net Weight	714 g
