Page #211 background image
8. White Balance/Image Quality
211
Adjusting Image Quality
1
Press 21 to select the type of Photo Style.
2
Press 34 to select an item and then
press 21 to adjust.
0
Adjusted items are indicated with [¢].
3
Press or .
0
When the image quality is adjusted, the
Photo Style icon on the recording screen is
indicated with [¢].
Settings Items (Image Quality Adjustment)
[Contrast] Adjusts the contrast in the image.
[Highlight] Adjusts the brightness of bright areas.
[Shadow] Adjusts the brightness of dark areas.
[Saturation] Adjusts the vividness of colors.
[Color Tone] Adjusts blue and yellow tints.
[Hue]
Assuming that the reference point is red, this rotates the
hue toward violet/magenta or yellow/green to adjust the
coloring of the entire image.
[Filter Effect]
[Yellow]
Enhances the contrast. (Effect: weak)
Records the sky with a clear blue.
[Orange]
Enhances the contrast. (Effect: medium)
Records the sky with a darker blue.
[Red]
Enhances the contrast. (Effect: strong)
Records the sky with a much darker blue.
[Green]
Skin and lips of people appear in natural
tones.
Green leaves appear brighter and more
enhanced.
[Off] s
6WDQGDUG
-
5
-
500
+5+5
±0
±0
±0
±0
±0
