17. Materials
559
35 mm full-frame interchangeable lens:
S-R2060 “LUMIX S 20-60 mm F3.5-5.6”
Mount Leica Camera AG L-Mount
Focal length f=20 mm to 60 mm
Lens construction 11 elements in 9 groups (2 aspherical lenses, 3 ED
lenses, 1 UHR lens)
Aperture type 9 diaphragm blades/Circular aperture diaphragm
Maximum aperture F3.5 (Wide) to F5.6 (Tele)
Minimum aperture value F22
Angle of view 94o (Wide) to 40o (Tele)
In focus distance 0.15 m (0.49 feet) to ¶ (Wide to focal length 26 mm)/
0.4 m (1.31 feet) to ¶ (Tele) (from the focus distance
reference line)
Maximum image
magnification
0.43k (focal length 26 mm)
Optical Image Stabilizer No
Filter diameter 67 mm
Maximum diameter ‰77.4 mm (3.0q)
Overall length Approx. 87.2 mm (3.4q) (from the tip of the lens to the
base side of the lens mount)
Mass (Weight) Approx. 350 g (0.77 lb)
Dust and splash resistant Yes
Recommended operating
temperature
j10 oC to 40 oC (14 oF to 104 oF)
Permissible relative
humidity
10 %RH to 80 %RH
