Panasonic SA-MAX200PH - SMPS P.C.B.

102
16.1.10. Mic P.C.B.
16.1.11. SMPS P.C.B.
REF NO.
MODE 1234567891011121314
POWER ON 0 0 6.0 6.0 6.0 6.0 6.0 0 12.1 6.0 0 0.9 12.1 6.0
STANDBY 0 0 6.0 6.0 6.0 6.0 6.0 0 12.1 6.0 0 0.9 12.1 6.0
IC6300
SA-MAX200PH MIC P.C.B.
REF NO.
MODE 12345678
POWER ON 0 18.9 0 1.6 0.3 7.0 0 0
STANDBY 0 18.9 0 1.6 0.3 7.0 0 0
REF NO.
MODE 12345678
POWER ON 5.8 0.6 2.3 0.2 163.0 0 0 0
STANDBY 5.8 0.6 2.3 0.2 163.0 0 0 0
REF NO.
MODE K A R
POWER ON 33.6 0 2.5
STANDBY 33.6 0 2.5
REF NO.
MODE K A R
POWER ON 2.3 0 2.5
STANDBY 2.4 0 2.5
REF NO.
MODE S D G E C B E C B E C B E C B
POWER ON 0 0 0 0 14.0 0 4.8 5.7 5.1 20.0 19.5 18.9 0 37.4 0
STANDBY 0 0 0 0 14.0 0 4.7 5.7 5.1 20.0 19.5 18.9 0 37.4 0
REF NO.
MODE E C B E C B
POWER ON 0 1.6 0.4 0 0 3.3
STANDBY 0 1.6 0.4 0 0 3.3
IC5790
IC5801
IC5701
IC5899
Q5898 QR5810
SA-MAX200PH SMPS P.C.B.
Q5700 Q5711 Q5720 Q5721 Q5803
