17 Schematic Diagram Notes
• This schematic diagram may be modified at any time
with the development of new technology.
Notes:
• Important safety notice:
Components identified by mark have special characteris-
tics important for safety.
Furthermore, special parts which have purposes of fire-retar-
dant (resistors), high quality sound (capacitors), low-noise
(resistors), etc are used.
When replacing any of components, be sure to use only
manufacturer’s specified parts shown in the parts list.
• In case of AC rated voltage Capacitor, the part no. and val-
ues will be indicated in the Schematic Diagram.
AC rated voltage capacitor:
C5700, C5701, C5703, C5704, C5705, C5706, C5707,
• Resistor
Unit of resistance is OHM [Ω] (K=1,000, M=1,000,000).
• Capacitor
Unit of capacitance is µF, unless otherwise noted. F=Farad,
pF=Pico-Farad
• Coil
Unit of inductance is H, unless otherwise noted.
•
*
For indication only.
• Test Pad
: Test Pad Position.
• Voltage and signal line
S951: Mode Switch.
S952: Half Switch.
S953: REC Switch.
S954: RECINH_R Switch.
S6100:
Power ( ) Switch.
S6101: USB REC.
S6104: Surround Switch.
S6106:
Tape REC ( ) Switch.
S6108: H.Bass Switch.
S6201: Open/Close ( ) Switch.
S6202:
Exchange ( ) Switch.
S6203:
Disc 1 ( ) Switch.
S6204:
Disc 2 ( ) Switch.
S6205:
Disc 3 ( ) Switch.
S6206:
Disc 4 ( ) Switch.
S6207:
Disc 5 ( ) Switch.
S6208:
Stop/-Demo ( STOP/DEMO) Switch.
S6300:
/Forward ( ) Switch.
S6301: Manual EQ Switch.
S6302:
/Rewind ( ) Switch.
S6303:
USB (USB ) Switch.
S6304:
Tape ( ) Switch.
S6306: DVD/CD Switch.
S6307: FM/AM Switch.
S6308: EXT-IN Switch.
S6820:
Open ( ) Switch.
VR6001: MIC VOL Jog.
VR6500: Volume Jog.
VR6630: Bass Control Jog.
: +B signal line
: -B signal line
: USB signal line
: CD/DVD/Tape Audio Input signal line
: CD/DVD Video Input signal line
: CD/DVD Audio & Video Input signal line
: AM/FM signal line
: AUX /Mic /Music Port/Audio Input signal
line
: Audio Output Signal Line
: Video Output Signal Line
To Next Page
