20 Terminal Function of ICs
20.1. IC2801 (RFKWMVK480GC): IC
Microprocessor
20.2. IC6601(C0HBB0000057): IC FL
Driver
Pin No. Terminal Name I/O Function
1 LM I Level Meter Left
2 NC - No Connection
3 NC - No Connection
4 Wide1 - No Connection
5 DVD_PCONT O Power Control pin for DVD Mod-
ule
6 DVD_Mute I Signal from DVD module control
mute circuit
7 F_HOP O F_Hop for Digital Amplifier
8 BYTE - External Data Bus Width Select
Input (Connect to Ground)
9 EFP_CNVss - Flash Mode Terminal
10 Xc_in - 32.768 kHz Sub Clock
11 Xc_out - 32.768 kHz Sub Clock
12 EFP_RESET - Reset Input (ACTIVE L)
13 Xout - 10 Mhz Main Clock
14 Vss - Ground ( 0V )
15 Xin - 10 Mhz Main Clock
16 Vcc - Power Supply (+5V)
17 NMI - Connect to Vcc (+5V)
18 RMT I Remote Control Input
19 NC No Connection
20 SYNC I AC Failure Detect Input
21 ST/DO I Tuner IF Data / Stereo Input
22 SD I Tuner Signal Detect Input
23 NC - No Connection
24 NC - No Connection
25 NC - No Connection
26 ASP_DATA O ASP DATA
27 ASP_CLK O ASP CLOCK
28 NC No Connection
29 PLL_DATA O PLL DATA
30 PLL_CLK O PLL CLOCK
31 REG1/
EFP_TxDI
I TUNER Region Setting 1/Flash
TX for on board writer
32 REG2/
EFP_RxDI
I TUNER Region Setting 2/Flash
RX for on board writer
33 REG3/
EFP_SCLK
I TUNER Region Setting 3/CLK
for on board writer
34 EFP_BUSY I EFP BUSY
35 DVD_CMD O CMD Signal for DVD Module
36 DVD_STA I STATUS Signal from DVD mod-
ule
37 DVD_CLK I CLOCK Signal from DVD mod-
ule
38 MODEL_SELEC
T
I No Connection
39 MOD_DA O Digital Amplifier Muting
40 MUTE_A O Audio Mute
41 EE_CS/EFP/
EPM
O EEPROM Chip Select
42 EE_CLK O/I EEPROM CLOCK
43 EE_DATA O/I EEPROM DATA
44 SW_1 - No Connection
45 SW_2 - No Connection
46 PCONT O Main Transformer Control Output
47 DC_DET1 I DC Detect Input
48 DC_DET2 I DC Detect Input
49 NC - No Connection
50 NC - No Connection
51 BASS_1 I Bass Control 1
52 BASS_2 I Bass Control 2
53 H.BASS LED O dimmer control
54 VOL LED O dimmer control
55 NC - No Connection
56 PLUNGER O Deck plunger control
57 MOTOR O Deck motor control
58 NC - No Connection
59 NC - No Connection
60 DMT - No Connection
61 REC O Deck Recording control
62 Vcc - Power Supply (+5V)
63 TAPE EJECT I Deck Eject
64 Vss - Ground (0V)
65 HP_SW I Head Phone Detection
66 MPORT_SW I Music Port Detection
67 MIC mute O Mute when Mic is in
68 AM_BP O AM Beaf Proof
69 ECHO_ 1 - No Connection
70 ECHO_ 2 - No Connection
71 Ripping LED O LED for USB ripping
72 FL_CS O FL Driver Chip Select
73 FL_ DATA O Serial Data to FL Driver
74 FL_CLK O Serial Clock to FL Driver
75 NC O No Connection
76 ECHO_MUTE - No Connection
77 TOP SWITCH I TOP SENSOR (CR14)
78 CLOSE I CLOSE SWITCH (CR14)
79 LO_F O Mecha loading mechanism
80 LO_R O Mecha loading reverse
81 HOME_CR I Home Sensor (CR14)
82 TRAY_CW_H O Tray close signal
83 TRAY_CCW_L O Tray open signal
84 OPEN I Open Switch (CR14)
85 MODE I MODE Sensor (CR14)
86 UD_SENSOR I CR14 control Position detect
87 UNLOAD SW I Unload Switch (CR14)
88 INNER_SW I Inner Switch (CR14)
89 DVD_REG I DVD Region Setting
90 MK_IN2 I Mecha condition input 2 (Photo/
TPS)
91 VOL_JOG I Volume control
92 KEY3 I Keyline 3 input
93 KEY2 I Keyline 2 Input
94 KEY1 I Keyline 1 input
95 MK_IN 1 I Mecha condition input 1 (MODE,
HALF)
96 AVss - Analog Power Supply Input
(Connect to Ground)
97 MK_IN3 I Mecha condition input 3
(RECINH_F, RECINH_R)
98 Vref - Reference for A-D (+5V)
99 AVcc - Analog Power Supply Input
100 NC - No Connection
Pin
No.
Terminal Name I/O Function
1 P0 O No Connection
2 P1 - No Connection
3 P2 - No Connection
4 P3 - No Connection
5 OSC I Oscillator Input
6 NC - No Connection
