Drive Type: 3ø, Fundamental Voltage = 400V
Line Inductance = 146µH, PSCC = 5kA
These products are designated as “Professional Equipment” as defined in EN61000-3-2.
Frame Size:
2
3
Product Code:
15G-42-0065...
15G-42-0090...
15G-43-0120…
Power Rating (kW):
2.2
4
5.5
Current Rating (A):
6.5
9
12
Harmonic No.
RMS Current (A)
1
5.99
8.21
10.76
3
0.00
0.00
0.00
5
3.90
5.26
6.23
7
2.39
3.14
3.22
9
0.00
0.00
0.00
11
0.39
0.36
0.76
13
0.54
0.68
0.93
15
0.00
0.00
0.00
17
0.29
0.30
0.15
19
0.12
0.11
0.34
21
0.00
0.00
0.00
23
0.20
0.23
0.11
25
0.11
0.10
0.12
27
0.00
0.00
0.00
29
0.10
0.13
0.10
31
0.10
0.11
0.03
33
0.00
0.00
0.00
35
0.03
0.05
0.09
37
0.06
0.08
0.02
39
0.00
0.00
0.00
40
0.00
0.00
0.00
Total RMS Current (A):
7.58
10.28
12.90
THD: Current (%):
77.59
75.39
66.30
