Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 113 (125)
Power Supply = 3ø 380-480V ±10%, 50/60Hz ±10%, PSCC = 5kA
Motor power, output current and input current must not be exceeded under steady state operating
conditions.
Minimum repetitive power up / power down cycle time = 10 mins.
Frame
Size
Product Code
Motor
Power
(kW)
Output
Current
(A)
Input
Current
(A)
Est. Eff
(%)
Switching
Freq (kHz)
nom / max
AC
Current
Derate
(%/kHz)
5
15G-45-0380...
18.5
38
44
97
4 / 10
4.0
15G-45-0440...
22
44
51
98
4 / 10
5.3
15G-45-0600...
30
60
70
96
4 / 10
5.8
13.3 Internal Brake Switch Ratings
1ø, 230V Products
DC Link Brake Switch Threshold = 382V
Frame
Size Product Code
Motor
Power
(kW)
Continuous Peak (Instant)
Min
Resistor
Value
(Ω)
Brake
Current
(A)
Power
Diss
(kW)
Brake
Current
(A)
Power
Diss
(kW)
1
15G-11-0025...
0.37
1.0
0.37
4.8
1.8
80
15G-11-0045...
0.75
2.0
0.75
4.8
1.8
80
15G-11-0070...
1.5
3.9
1.5
4.8
1.8
80
2
15G-12-0100...
2.2
4.8
1.8
4.8
1.8
80
Note: Peak (Instant) = Maximum 20sec, 30% ‘on’ duty (except where this value is the same as the
continuous rating)
3ø, 230V Products
DC Link Brake Switch Threshold = 382V
Frame
Size
Product Code
Motor
Power
(kW)
Continuous Peak (Instant)
Min
Resistor
Value
(Ω)
Brake
Current
(A)
Power
Diss
(kW)
Brake
Current
(A)
Power
Diss
(kW)
1
15G-11-0025...
0.37
1.0
0.37
4.8
1.8
80
15G-11-0045...
0.75
2.0
0.75
4.8
1.8
80
15G-11-0070...
1.5
3.9
1.5
4.8
1.8
80
2
15G-12-0100...
2.2
4.8
1.8
4.8
1.8
80
3
15G-33-0170...
4
10.5
4.0
12.7
4.9
30
4
15G-34-0210...
5.5
12.7
4.9
12.7
4.9
30
5
15G-35-0300...
7.5
19.6
7.5
25.5
9.7
15
15G-35-0400...
11
28.8
11.0
34.7
13.3
11
Note: Peak (Instant) = Maximum 20sec, 30% ‘on’ duty (except where this value is the same as the
continuous rating)
