Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
12 (125) DOC-0017-03-EN-B 04.04.2023
5 Product Overview
General Overview:
Power Range:
0.37 – 30kW
Frame Sizes:
5 (Frames 1 – 5)
Power Supply:
1ø 220 – 240Vac ±10%, (Frames 1 - 2: 0.37 – 2.2kW)
3ø 220 – 240Vac ±10%, (Frames 1 - 5: 0.37 – 11kW)
3ø 380 – 480Vac ±10%, (Frames 1 - 5: 1.5 – 30kW)
Input Frequency:
50/60Hz ±10%
Output Frequency:
0.5 – 590Hz
Safe Torque Off (STO):
SIL2, PLd
Environment:
Temperature:
Frame 1, 1ø 230V, 0.37kW (Fan-less):
- 0 - 40°C
All other products:
- 0 - 40°C (derate output current above 40°C by 2% per °C, up to
maximum of 45°C)
Altitude:
0 – 1000m (derate output current above 1000m by 1% per 100m, up to
maximum of 2000m)
