Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
110 (125) DOC-0017-03-EN-B 04.04.2023
12 AC15 Series Product Codes
1
2
3
4
5
6
Order example
15G
-
1
1
-
0025
-
B
F
1
Device Family
15G
AC15 Series, General Purpose AC Drive
2
Voltage
1
230Vac, Single Phase
3
230Vac, Three Phase
4
400Vac, Three Phase
3 & 4
Frame Size and Current Rating (Heavy Duty)
Frame Size - Current Rating (Power)
230Vac, Single Phase Supply Voltage
1-0025
Frame 1 - 2.5A (0.37kW)
1-0045
Frame 1 - 4.5A (0.75kW)
1-0070
Frame 1 - 7A (1.5kW)
2-0100
Frame 2 - 10A (2.2kW)
230Vac, Three Phase Supply Voltage
1-0025
Frame 1 - 2.5A (0.37kW)
1-0045
Frame 1 - 4.5A (0.75kW)
1-0070
Frame 1 - 7A (1.5kW)
2-0100
Frame 2 - 10A (2.2kW)
3-0170
Frame 3 - 17A (4.0kW)
4-0210
Frame 4 - 21A (5.5kW)
5-0300
Frame 5 - 30A (7.5kW)
5-0400
Frame 5 - 40A (11kW)
400Vac, Three Phase Supply Voltage
1-0012
Frame 1 - 1.2A (0.37kW)
1-0020
Frame 1 - 2A (0.75kW)
1-0040
Frame 1 - 4A (1.5kW)
2-0065
Frame 2 - 6.5A (2.2kW)
2-0090
Frame 2 - 9A (4.0kW)
3-0120
Frame 3 - 12A (5.5kW)
3-0170
Frame 3 - 17A (7.5kW)
4-0230
Frame 4 - 23A (11kW)
4-0320
Frame 4 - 32A (15kW)
5-0380
Frame 5 - 38A (18.5kW)
5-0440
Frame 5 - 44A (22kW)
5-0600
Frame 5 - 60A (30kW)
5
Brake Switch
B
Brake Switch Fitted
6
EMC Filter
F Category C3 Filtered
