DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 11 (125)
Initial Steps
Use this Hardware Installation Manual to help plan the following:
1. Installation
Know your requirements:
- Certification, i.e. CE, UL, CUL compliance (Chapter 11: Compliance).
- Conformance to local installation requirements.
- Supply and Cabling requirements (Chapter 6: Installation).
2. Motor Considerations
It is important to consider that:
- The motor used with the Inverter is suitable for Inverter duty.
- The rated current of the motor used with the Inverter is not less than 25% of the Inverter
current rating. It this is the case, poor motor control or autotune problems may occur.
Unpacking the Product
When unpacking the product:
- Save the packaging. In case of the need to return the product, improper packaging can result in
transit damage.
- Use safe and suitable lifting procedure when moving the unit. Never lift the unit by its terminal
connections.
- Prepare a clear, flat surface to receive the inverter before attempting to move it. Do not damage
any terminal connections when putting the unit down.
- Refer to ‘Chapter 6: Installation’ for further details on handling the products.
