Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 15 (125)
6 Installation
IMPORTANT
Please ensure that you have read and are familiar with the ‘Compliance’
chapter before installing the unit.
6.1 Mechanical
Product Dimensions & Weights
Optional Wiring Bracket shown for reference only
Frame
Size
Product Dimensions
Weight H H1 H2 W D
1
138.0
(5.43)
151.0
(5.94)
175.1
(6.89)
81.5
(3.21)
144.3
(5.68)
1.1
(2.43)
2
180.0
(7.09)
193.0
(7.60)
227.5
(8.96)
108.4
(4.27)
185.0
(7.28)
2.0
(4.41)
3
237.5
(9.35)
248.0
(9.76)
281.9
(11.10)
141.6
(5.57)
184.0
(7.24)
3.3
(7.28)
4
265.0
(10.43)
283.0
(11.14)
321.4
(12.65)
161.0
(6.34)
196.0
(7.72)
4.4
(9.70)
5
340.0
(13.39)
358.0
(14.09)
401.4
(15.80)
210.0
(8.27)
220.2
(8.67)
8.0
(17.64)
All dimensions in millimeters (inches)
All weights in kilograms (lbs)
