Cable Connection
The control module terminal cover will need to be removed prior to connecting the remote 6901 MMI cable.
To remove the cable, push the connector clip up towards the cable and pull away from the product.
1. Insert the cable connector clip side
down into the RJ11 port on the front
of the product.
