Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
16 (125) DOC-0017-03-EN-B 04.04.2023
Product Fixing Dimensions
Frame
Size
Fixing Dimensions
Slot Size
Fixings
H3
H4
W1
W2
K
R1
R2
1
128.0
(5.04)
5.0
(0.20)
70.0
(2.76)
5.7
(0.22)
5.0
(0.20)
2.3
(0.09)
4.7
(0.19)
M4
2
170.0
(6.69)
5.0
(0.20)
94.0
(3.70)
7.2
(0.28)
5.0
(0.20)
2.3
(0.09)
4.7
(0.19)
M4
3
225.0
(8.86)
6.5
(0.26)
126.0
(4.96)
7.8
(0.31)
6.0
(0.24)
3.0
(0.12)
5.3
(0.21)
M5
4
255.0
(10.04)
5.0
(0.20)
146.0
(5.75)
7.5
(0.30)
5.0
(0.20)
2.5
(0.10)
4.6
(0.18)
M5
5
329.0
(12.95)
5.5
(0.22)
194.0
(7.64)
8.0
(0.31)
6.0
(0.24)
3.0
(0.12)
5.5
(0.22)
M5
All dimensions in millimeters (inches)
