DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 35 (125)
6.4 Remote Mounted 6901 MMI
In addition to the Drive mounted keypad, there is a RJ11 port available to the user for connecting a remote
mounted 6901 Keypad.
The 6901 can be useful when performing commissioning functions, or when a 6901 MMI is to be mounted
remotely, i.e., on the door of a control cubicle.
Order Codes
Installation
The remote mounting kit (6052-00-G) is supplied with instructions and a 1-to-1 fixing template to be used
during installation:
