User +24V Output
Terminal Idents:
24V referenced to 0V
Nominal Output Voltage:
23V
Minimum Output
Voltage:
20V @ 50mA
Maximum Output
Current:
Frame 1:
- 50mA (Total combined with DX1 & DX2 outputs)
Frames 2 – 5:
- 50mA
Isolated:
No
Over Current Protection:
Yes
External +24V Auxiliary Input
Allows for the partial power-up of the product without mains power applied, for programming of the drive
using the DSELite programming tool through the Ethernet port. µSD Card port and digital I/O are also
active.
Terminal Idents:
0V, 24V
Input Voltage:
24V +/-10% (up to a maximum ambient temperature of 40°C)
24V +5 / -10% (up to a maximum ambient temperature of 45°C)
Indicative Input Current:
@Nominal 24V:
- Control Board only (unloaded): 35mA
Isolated:
No
Over Voltage Protection:
No
Reverse Voltage
Protection:
No
STO Inputs
Terminal Idents:
STOA, STOB, referenced to 0V
Nominal Input Voltage:
24V PELV (with energy source class 3, according to IEC 62368-1)
Maximum Input Voltage:
25.2V (26.4V in a maximum operating ambient of 40°C)
Recommended Input
Voltage for Logic Low
Level:
0V – 5V (or open circuit)
Recommended Input
Voltage for Logic High
Level:
15V – 24V
Indetermined Input
Range:
5V – 15V, function is undefined
Typical Input Current:
9mA @ 24V
STO Input Operability:
Always Active (i.e., STO cannot be disabled by the drive firmware)
STO User Input A Logic
Level:
0V or open circuit = STO Activated
24V = STO Disabled
STO User Input B Logic
Level:
0V or open circuit = STO Activated
24V = STO Disabled
Isolation:
Channel A & B to SELV: Galvanic Isolation.
Channel A to Channel B: Non-isolated
