Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
86 (125) DOC-0017-03-EN-B 04.04.2023
Standards
Limits*
Product
Specific
Generic
Frequency (MHz) dB(µV/m)
EN 61800-3 EN61000-6-3 EN61000-6-4
Category C3
These limits have no
relationships with the generic
standards.
30 - 230 50
230 - 1000 60
* = Limit has been adjusted for a measurement distance of 10m.
For category C1, if the field strength measurement at 10m cannot be made because of high ambient
noise levels or for other reasons, the measurement may be made at 3m.
If the 3m distance is used, the measurement result obtained shall be normalised to 10m by subtracting
10dB from the result.
In this case, care should be taken to avoid near field effects, particularly when the PDS (Power Drive
System) is not of an appropriately small size, and at frequencies near 30MHz.
When multiple drives are used, 3dB attenuation per drive needs to be added.
Conducted Emissions: Standards
The Conducted Emissions standards have common roots (CISPR 11 & CISPR14), so there is some
commonality in the test levels applied in different standards and environments as shown in the table below:
Standards
Limits*
Product
Specific
Generic
Frequency
(MHz)
Quasi Peak
(dB/
µ
V)
Average
(dB/
µ
V)
EN 61800-3 EN61000-6-3 EN61000-6-4
Category C1 Equivalent Not applicable
0.15 - 0.5 66 > 56
†
56 > 46
†
0.5 - 5.0 56 46
5.0 - 30.0 60 50
Category C2 Not applicable Equivalent
0.15 - 0.5 79 66
0.5 - 5.0 73 60
5.0 - 30.0 73 60
Category C3
(I ≤ 100A)
These limits have no
relationships with the generic
standards.
0.15 - 0.5 100 90
0.5 - 5.0 86 76
5.0 - 30.0 90 > 70
†
80 > 60
†
Category C3
(I ≥ 100A)
These limits have no
relationships with the generic
standards.
0.15 - 0.5 130 120
0.5 - 5.0 125 115
5.0 - 30.0 115 105
†
= Limit decreases with the Log of frequency for the specified frequency range
