NAT/NAPT configuration task list 137
SmartWare Software Configuration Guide 11 • NAT/NAPT configuration
Activate NAT/NAPT
To activate a NAT/NAPT component, bind its NAPT profile to an IP interface. This binding identifies the
global interface of the respective NAT/NAPT component. All other IP interfaces are local relative to this NAT/
NAPT.
Note If both a NAPT profile and an ACL profile are bound to the same IP inter-
face, the ACL (Access Control List) acts on the local side of the NAT/
NAPT component.
Procedure: To activate a NAT/NAPT component
Mode: Configure
Example: Configuring NAPT Interface
The following example shows how to activate a NAT/NAPT component with the NAPT profile access on the
IP interface lan.
node(cfg)#context ip router
node(ctx-ip)[router]#interface lan
node(if-ip)[lan]#use profile napt access
Displaying NAT/NAPT configuration information
Two commands are available to display an existing NAPT profile. There is no command yet to display the
dynamic entries of a NAT/NAPT component.
Procedure: To display NAT/NAPT configuration information
Mode: Configure
Step Command Purpose
1 node(cfg)#context ip router Selects the IP router context
2 node(ctx-ip)[router]#interface
name
The NAPT profile shall be used on the interface name
3 node(if-ip)[name]#use profile
napt profile
Defines that the NAPT profile profile shall be used on
the interface name
Step Command Purpose
1 node(cfg)#show profile napt Displays the available NAPT profiles
2 node(cfg)#show profile napt
name
or
node(cfg)#show napt interface
name
Displays the NAPT profile name
or
Displays the NAPT profile bound to the IP interface
name
