FXO interface configuration task list 414
SmartWare Software Configuration Guide 36 • FXO interface configuration
Mode: Interface FXO
Now we can apply the PSTN profile for the FXO interface named name as follows.
Configuring when the digits are dialed (optional)
When the FXO port goes off-hook to make an outgoing call, the FXS switch normally sends a dial-tone to
indicate it is ready to received dialed digits. Alternatively, you can specify the FXO interface to wait a specific
period of time after going off-hook before dialing the first digit.
Note All countries do not have the same dial-tone. For information on configur-
ing the dial-tone for your country, refer to chapter 42, “Tone configuration”
on page 524.
The default setting is to wait for the dial-tone. Choosing to wait a specific time after dial-tone, the variable is
timeout, the number of seconds to wait. Zero (0) seconds means that the interface dials immediately.
Step Prompt, command & response Purpose
1 node> Basic prompt in Operator Exec mode
2 node>enable Enters Administration execution mode
node# Response: The prompt in administration execu-
tion mode is the #
3 node#configure Enters the Configure configuration mode
node(cfg)# Response: The prompt in the Configure configu-
ration mode is (cfg)#
4 node(cfg)#context cs Enters the Context CS configure mode
node(ctx-cs)[switch]# Response: The prompt in the Context CS configu-
ration mode is (ctx-cs)[switch]#
5 node(ctx-cs)[switch]#interface fxo if-name Enter the Interface FXO configuration mode
node(if-fxo)[if-name]# Response: The prompt in the Interface FXO con-
figuration mode is (if-fxo)[if-name]#
Step Prompt, command & response Purpose
6 node(if-fxo)[if-name]#[no] use profile pstn profile-name The “profile pstn” command is
applied to the FXO interface
named if-name
node(if-fxo)[if-name]# Response: You are now in the
FXO interface configuration
mode. In this mode, you may con-
figure the parameters for the FXO
interface name.
